Modular System Standard Office Container MB20(SH) Description:

PRICE INCLUDES

• Modular building in open-plan; as seen in the layout drawing



PRICE DOES NOT INCLUDE

• Hi-ab crane
• Delivery
• VAT
• Extras
• Side windows are considered extras and are not included in the price
• Concrete blocks



Dimensions
External dimensions: 6058x2438x2800mm

Internal height: 2500mm

Frame
Container steel construction in the EXC2 class according to PN EN 1090-1, made of cold-bended profiles, joined by welding according to PN EN ISO 3834-2. The product has CE marking, – steel frame abrasive blast cleaned to Sa 2.5 according to PN EN ISO 8501 -1 in a closed blasting chamber, spray-painted in a spray booth and dried in a cabin-dryer,- transport handles (according to ISO standards) located in the corners

Roof
– layered roof: * 0.55 mm steel galvanized sheet, * 10 mm chipboard, * 80mm mineral wool insulation, * vapour barrier made of polyethylene film, * 12 mm laminated chipboard, – no gutter system, drainage of rainwater through the walls

Walls
Interchangeable composite panels: * wooden framework. * from the outside, 0.55 mm trapezoidal sheet, galvanized, painted, * 60 mm mineral wool insulation, * polyethylene film, * on the inside 12 mm laminated chipboard, white,

Floor
Layered floor: * floor finish: 1,5 mm PVC floor lining, gray – welded at joints + PVC floor strips, grey, * 22 mm PS chipboard, * polyethylene film, * 60 mm mineral wool insulation, * 0.5 mm galvanized corrugated sheet with low profile rib height,

Door
Steel, single-door, dimensions: 900 mm x 2000 mm (according to the drawing), thermally insulated, equipped with a lock, lock cylinder + 3 keys, signboards, door handle

Window
PVC, tilt-turn, (and/or according to the drawing), – insulated glass units with U = 1,1 W/m2K

Electrical system
Electrical, flush-mounted installation (covered), – 8MOD circuit breaker panel (switchgear), – power system: 230V sockets (according to the drawing), – lighting system: fluorescent luminaries, IP65 protection class. with 2x16W LED lamps (according to the drawing), – external connection of the installation based on a 5x32A socket and power plug, – earthing of the container frame by means of a wire fastened with an M10 screw

Heating
Convector electric heater (according to the drawing)
